1
Installation and Operating Instructions for
MCA CONTROL VALVE
Top Mount Anion Resin Unit
Model #:
____ MP-MCAD-30T 1.0 CF Dealkalizer
____ MP-MCAD-45T 1.5 CF Dealkalizer
____ MP-MCAD-60T 2.0 CF Dealkalizer
____ MP-MCAN-30T CS Crawl Space Nitrate Removal
____ MP-MCAN-30T 1 CF Nitrate Removal
____ MP-MCAN-45T 1.5 CF Nitrate Removal
____ MP-MCAN-60T 2.0 CF Nitrate Removal
____ MP-MCAT-30T 1.0 CF Tannin Removal
____ MP-MCAT-45T 1.5 CF Tannin Removal
____ MP-MCAT-60T 2.0 CF Tannin Removal
____ MP-MCAU-30T 1 CF Uranium Removal
____ MP-MCAU-45T 1.5 CF Uranium Removal
____ MP-MCAU-60T 2.0 CF Uranium Removal
Shipping Carton Description / unit:
# of
cartons
Contents
Description
1
Mineral tank
Distributor pipe installed
1
Brine tank
*NOTE: MCA valve is shipped in brine tank.
1
MP MCA control
valve
MP MCA timer and backwash flow control
and bypass with tail piece kit
NOTE: THIS ANION UNIT IS NOT INTENDED TO BE USED FOR TREATING
WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNKNOWN QUALITY
WITHOUT ADEQUATE DISINFECTION WHETHER BEFORE OR AFTER THE SYSTEM
Anion Unit Positioning:
1. Place Anion unit in desired position, far enough from walls and
other obstructions to allow for servicing the unit.
2. Place the Anion unit within reasonable access to a grounded
115V/60 HZ circuit and a legal drain line connection.
