Note: In need of disassembling, dismantle the wheel in the opposite way of
installation.
Front wheel:
Insert into axle slots.
Install the tab washer (a)
.
Then install the axle nut (b).
Tighten the nut
with
wrench.
During wheel
installatio
n make
sure the
brake
rubber
pad is
parallel
with the
wheel rim with a
clearance of 1.5
–
2mm in between.
