4110.607
19
19
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
1 4104.006 Upper Shell 1
2 4109.590 Screw/Lockwasher, 1/2" 8
3 4101.180 Combustion Chamber 1
4 4103.537 Photocell Bracket 1
5 4110.564 Photocell Assembly 1
6 4100.632 Drain Plug 1
7 4103.529 Screw, #6-32 x 3/8" 2
8 ** Burner Head Assembly 1
8-1 4103.559 Nozzle 1
8-2 4100.525 Nozzle Seal Washer 2
8-3 4100.533 Nozzle Seal Spring 1
8-4 4101.622 Nozzle Seal Sleeve 1
8-5 4109.352 Burner Head Body 1
8-6 4104.118 Barb Fitting 2
8-7 4101.846 Spark Plug 1
9 4110.124 Screw/Lockwasher, 1/2" 13
10 4104.147 Air Line 1
11 4104.097 Fuel Line 1
12 4105.062 Fan 1
13 ** Motor and Pump Assembly 1
13-1 4100.652 Motor with capacitor 1
13-2 4101.317 Pump Body 1
13-3 4108.588 Screw, #10-32 x 5/8" 2
13-4 4108.635 Insert 1
13-5 4108.627 Rotor 1
13-6 4101.325 End Pump Cover 1
13-7 4101.358 Intake Filter 1
13-8 4108.643 End Filter Cover 1
13-9 4108.379 Steel Ball (1/4" Dia.) 1
13-10 4102.141 Pressure Relief Spring 1
13-11 4102.133 Adjusting Screw 1
13-12 4102.125 Plug 1
13-13 4108.528 Screw, #10-32 x 1" 4
13-14 4101.341 Output Filter 1
13-15 4108.528 Screw, #10-32 x 1" 6
13-16 4101.333 Lint Filter 1
13-17 4104.118 Barb Fitting 1
13-18 4101.22 Blade 4
14 4103.695 Fan Guard 1
KEY PART PART
NO. NUMBER DESCRIPTION QTY.
15 4150.553 Rubber Bumper 2
16 4103.850 Edge Liner 1
17 4101.240 Motor Bracket 1
18 4100.527 Lock Washer, #10 2
19 4110.134 Nut, #10-32 3
20 4108.486 Hex locknut 2
21 4110.609 Electronic Ignitor 1
22 4108.510 Screw, #10-16 x 3/4" 2
23 4106.110 Terminal Board 1
24 4110.571 Rivet 1
25 4101.112 Bushing 1
26 4101.112 Bushing 1
27 4101.232 Bushing 2
28 4110.070 Button Plug 1
29 4105.287 Power Line RFI Filter 1
30 4108.126 Lower Shell 1
31 4104.170 Clip Nut 8
32 4110.133 Screw, #10-32 x 3/4" 1
33 4100.630 Fuel filter 1
34 4100.541 Rubber Bushing 1
35 4104.121 Fuel Line 1
36 4110.149 Fuel Tank 1
37 4103.891 Fuel Tank Cap 1
38 4110.195 Wire Assembly (red) 1
39 4104-196 Flame-Out Control 1
40 4150.528 Strain Relief Bushing 1
41 4110.563 Power Cord 1
42 4104.183 Side Cover 1
43 4109.592 Hex Nut 1
44 4104.336 Switch Cover 1
45 4110.164 Wire Assembly (black) 2
46 4106.179 ON/OFF Switch 1
PARTS AVAILABLE - NOT SHOWN
4105.292 Filler Neck Screen 1
4110.138 Tradename Decal 2
4110.196 Combustion Chamber
Ground Wire 1
4110.605 Decal Package 1
PARTS LIST
100,000 BTU/HR MODEL
**Not available as an assembly, order parts separately.
This list contains replaceable parts used in your heater. When ordering parts, be sure to
provide the correct model and serial numbers (from the model plate), then the part number
and description of the desired part.
PARTS LIST
100,000 Btu/Hr Model
