OWNER’S MANUAL
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 4104.006 Upper Shell 1
2 4109.590 Screw/Lockwasher, 1/2" 8
3 4100.640 Combustion Chamber 1
4 4100.658 Photocell Bracket 1
5 4103.529 Screw 2
6 4103.590 Photocell Assembly 1
7 ** Burner Strap Assembly 1
7-1 4100.645 Nozzle Assembly 1
7-2 4110.132 Ignitor Kit 1
7-3 4100.669 Screw, #6-32 x 7/8" 1
7-4 4109.560 Nozzle Adapter Bracket 1
7-5 4100.663 Nozzle Adapter 1
7-6 4100.660 Belleville Washer 1
8 4110.124 Screw/Lockwasher, 1/2" 2
9 4105.062 Fan 1
10 ** Motor and Pump Assembly 1
10-1 4100.652 Motor 1
10-2 4101.317 Pump Body 1
10-3 4108.588 Screw, #10-32 x 5/8" 2
10-4 4108.635 Rotor Insert 1
10-5 4108.627 Pump Rotor 1
10-6 4101.325 Pump End Cover 1
10-7 4101.358 Intake Filter 1
10-8 4108.643 Filter End Cover 1
10-9 4108.379 Steel Ball, 1/4" Diameter 1
10-10 4102.141 Relief Spring 1
10-11 4102.133 Adjusting Screw 1
10-12 4102.125 Plug 1
10-13 4108.528 Screw, #10-32 x 1" 10
10-14 4101.341 Output Filter 1
10-15 4101.333 Lint Filter 1
10-16 4104.118 Barb Fitting 1
10-17 4101.200 Blade 4
11 4150.553 Rubber Bumper 2
12 4110.186 Motor Mounting Bracket 2
12 4100.649 Button Plug 1
14 4110.142 Igniton Control Assymbly 1
PARTS LIST
B100CEL Model
This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the
correct model and serial numbers (from the model plate), then the part number and description of the
desired part.
** Not available as an assembly; order parts separately
KEY PART
NO. NUMBER DESCRIPTION QTY.
15 4108.486 Hex Lock Nut, 1/4-20 2
16 4103.659 Fan Guard 1
17 4100.632 Drain Plug (Includes “o” Ring) 1
18 4110.070 Button Plug 1
19 4110.032 Fuel Line 1
20 4100.630 Fuel Filter 1
21 4110.147 Fuel Line Tube 1
22 4100.541 Rubber Bushing 1
23 4110.147 Airline 1
24 4100.637 Lower Shell 1
25 4101.112 Bushing 1
26 4101.232 Bushing 1
27 4110.124 Screw/Lockwasher, 1/2" 6
28 4104.170 Clip Nut 8
29 4110.133 Screw, 1
30 4110.149 Fuel Tank 1
31 4103.891 Fuel Cap (Includes Gasket) 1
32 4100.654 P.C. Board Support 5
33 4150.528 Strain Relief Bushing 1
34 4110.038 Power Cord 1
35 4100.670 Side Cover 1
36 4110.124 Screw/Lockwasher, 1/2" 4
37 4100.656 Nylon Locknut 1
38 4110.036 Wire Assembly (Brown) 1
39 4100.667 ON/OFF Switch 1
40 4104.336 Switch Cover 1
41 4100.527 Lockwasher, #10 1
42 4110.134 Nut 3
43 4103.850 Edge Liner 1
44 4110.037 Wire Assembly (White) 1
PARTS AVAILABLE - NOT SHOWN
4105.292 Filler Neck Screen 1
4110.049 Wire Tie 1
4110.138 Tradename Decal 2
4110.146 Decal Package 1
4110.137 Ignition Control Assembly Fuse 1
