Master MAC-18W-DDF-A - Page 11













© 2015, Pinnacle Products International, Inc. 11 +9)$LU&LUFXODWRU8VHU¶V0DQXDO
´%$55(/)$10$&'')%
Figure 10: Exploded View of
MAC-24-DDF-B
1(9(5/($9($)$1
81$77(1'(':+,/(
23(5$7,1*25:+,/(
&211(&7('72$32:(5
6285&(
,QVWDOODWLRQDQG$VVHPEO\
1. Place the fan on level ground in a safe, desired
position then connect to an approved power source.
127(7KLVPRGHO&$1127EHZDOOPRXQWHG
([SORGHG9LHZ
5HSODFHPHQW3DUWV
,WHP 'HVFULSWLRQ 3DUW1XPEHU
1 Safety Guard - Front / Rear 95-032-2020
2 Fan Blade Assembly 95-003-2020
3 Motor 95-030-2020
4 Power Cord 95-026-2020
5 Power Switch 95-031-2020
6 Barrel 95-001-2000
7 Handle 95-006-2020
8 Knob Screw 95-015-2020
9 Rubber Spacer 95-015-2021
10 Fan Frame 95-009-2020
11 Wheel 95-008-2010
12 Cotter Pin 95-008-2011
