Master MCA Alliance Series - Installation and Operating Instructions

1
Installation and Operating Instructions for
Alliance Series Combination Systems
Model #:
_______ CFES-20/30/40T Birm Filter/Softener
_______ CNS-20/30/40T Neutralizer/Softener
_______ CTS-20/30/40T Activated Carbon/Softener
Shipping Carton Description:
Contents
Description
Mineral tank
Distributor pipe and softening resin installed
Brine tank
464 shutoff valve assembly
Control Valve
Control valve, bypass valve, and tailpiece kit
Filter Media is Packaged as Follows:
Model #
Media
CFES-20T
½ CF Birm
CFES-30T
1 CF Birm
CFES-40T
1 CF Birm
CNS-20T
½ CF NS Mix
CNS-30T
½ CF Calcite & ½ CF NS Mix
CNS-40T
½ CF Calcite & ½ CF NS Mix
CTS-20T
½ CF Activated Carbon
CTS-30T
1 CF Activated Carbon
CTS-40T
1 CF Activated Carbon
NOTE: This combination unit is not intended to be used for treating
water that is microbiologically unsafe or of unknown quality without
adequate disinfection whether before or after the system.
Water Softener Positioning:
1. Place combination unit in desired position, far enough from walls and
other obstructions to allow for servicing the unit.
2. Place the combination unit within reasonable access to a grounded
115V/60 HZ circuit and a legal drain line connection.
