18
21
10
48
62
16
16
Profundidad máx. M6x10
04. COTAS TÉCNICAS
METIS
SET
IRO
11
6
14
Profundidad
máx. 9
30
50
13 42
Ø12
14
9
17
13
10
10
53
48
63
Ø 12
Cuando el motor se alimenta, si no hay mandos a distancia memorizados, este ordena la ejecución de una serie de movimientos.
Si el motor no recibe un mando de radio válido en 15 segundos después de finalizar los 4 movimientos (véase el procedimiento abajo), este sale de
la programación y solo podrá accionarse a través del mando manual (ofreciendo de todos modos la posibilidad de regular los finales de carrera). Si
se quiere introducir el primer transmisor, basta cortar la corriente, esperar unos segundos y conectar nuevamente la corriente; entonces, se
reanudará el procedimiento 05.
ATENCIÓN: ¡Realice el siguiente procedimiento alimentando un solo motor a la vez!
05. INTRODUCCIÓN DEL PRIMER TRANSMISOR
Si el motor efectúa 4 movimientos de subida, pulse la
tecla SUBIDA del transmisor que quiere memorizar.
Si el motor efectúa 4 movimientos de bajada, pulse la
tecla BAJADA del transmisor que quiere memorizar.
B
ON
Alimente el motor.
A
x4
x4
ANTES DE 15 SEGUNDOS...
-
-
-
-
+
+
-
-
-
-
+
+
MOTOR A LA IZQUIERDAMOTOR A LA DERECHA
+ +
+
+
-
-
-
+ +
+
+
-
+
+
+
+
+
+
+
+
FINAL DE CARRERA SUPERIOR
FINAL DE CARRERA SUPERIOR
FINAL DE CARRERA INFERIOR
FINAL DE CARRERA INFERIOR
FINAL DE CARRERA SUPERIOR
FINAL DE CARRERA SUPERIOR
FINAL DE CARRERA INFERIOR
FINAL DE CARRERA INFERIOR
Si la tela se enrolla por detrás del rodillo, los tornillos de regulación quedan invertidos: el tornillo
azul regula el final de carrera inferior y el tornillo blanco regula el superior.
Si la tela se enrolla por detrás del rodillo, los tornillos de regulación quedan invertidos: el tornillo
azul regula el final de carrera inferior y el tornillo blanco regula el superior.
Si la tela se enrolla por detrás del rodillo, los tornillos de regulación quedan invertidos: el tornillo
azul regula el final de carrera superior y el tornillo blanco regula el inferior.
Si la tela se enrolla por detrás del rodillo, los tornillos de regulación quedan invertidos: el tornillo
azul regula el final de carrera superior y el tornillo blanco regula el inferior.
Tornillo AZUL
Tornillo AZUL
Tornillo AZUL
Tornillo AZUL
Tornillo BLANCO
Tornillo BLANCO
Tornillo BLANCO
Tornillo BLANCO
METIS
06. CÓMO REGULAR LOS FINALES DE CARRERA
MOTOR A LA IZQUIERDAMOTOR A LA DERECHA
SET
