MasterCraft 054-1250-0 User Manual

23
WARNING: When servicing, use only Mastercraft
®
replacement parts. Use of
any other parts may create a HAZARD or cause damage to your rotary tool.
Any attempt to repair or replace electrical parts on this rotary tool may create a
hazard unless repair is performed by a qualified technician. For more information,
call 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Rotary Tool
Key #
Part #
Part Name
Quantity
1
300082
Housing
1
2
242560
Suspension loop
1
3
315001
Cord clamp
1
4
500201
Screw
2
5
322004
Cord guard
1
6
160205
Cord set
1
7
163611
ON/OFF switch
1
8
222807
Brush holder
2
9
162407
Carbon brush
2
10
314507
Carbon brush cap
2
11
321005
Bearing sleeve
1
12
520008
Bearing 626-2RS
1
13
100088
Rotor
1
14
500001
Screw
6
15
300082
Housing
1
16
110088
Stator
1
17
313305
Head nut
1
18
312941
Shaft lock button
1
19
241506
Shaft lock spring
1
20
215014
Shaft lock pin
1
21
314009
Fan
1
22
520008
Bearing 626-2RS
1
23
213004
Output shaft
1
24
216500
Collet
1
25
2040150013
Collet nut
1
PARTS LIST - MODEL 054-1250-0
!
