19
headline bars
continuation tabs
notes
warnings
No. Part No. Description No. Part No. Description
1 3321558000 Left Housing 27 3520945000 Crank Roller
2 3402407000
Contact Receptacle
Assembly
28 5660027000 Circlips For Shaft
3 3128596000 Pendulum Lever 29 2823084000 Quick Clamp Assembly
4 3660050000 Spring B 30 5700305000 Upper Sliding Bearing
5 3700191000 Cap 31 3705624000 Sping Piece
6 3520668000 Pendulum Lever Shaft 32 2830082000 Electric Assembly
7 4870452000 Trigger Switch 33 3123507000 Transparent Cap
8 3128606000 Switch Button 34 5610103000 Tapping Screw
9 3660427000 Spring 35 3321557000 English Name
10 3126279000 Located Block 36 3126938000 Sleeve
11 3126278000 Switch Button 37 3705465000 Adjusting Lever
12 2730214000 DC Motor 38 3520719000 Clamp Washer
13 3520943000 Pinion 39 3704869000 Located Block
14 2823427000
Bearing Support
Assembly
40 5630046000 Nut
15 5650556000 Wash 41 5650199000 plain Washer
16 5700184000 Needle Bearing 42 5640213000 Flange Bolt
17 5650007000 Spring Washer 43 2822996000 Base Plate Assembly
18 3700197000 Washer 44 5650278000 Washer
19 5620038000 Screw 45 5620036000 Screw
20 3704792000 Pendulum Plate 46 3400175000 Knob
21 3704959000 Counterweight 47 3550177000
Guiding Roller Support
Pin
22 3550147000 Needle Pin 48 2822813000 Roller Support Set
23 3552550000 Bush 49 3126446000 Vacuum Adapter
24 5650555000 Washer 50 3700675000 Rip Fence
25 2823330000 Gear Set 51 3810049000 Jigsaw Blade
26 3700145000 Washer 52 3650185000 Wire Guard
If any parts are missing or damaged, or if you have any questions, please call the Toll-free Helpline,
at 1-800-689-9928.
PARTS LIST
