model no. 054-6841-4 | contact us 1-800-689-9928
12
7 Plain washer 8
8
Round-head square-neck bolt M6x26 1
9
Round-head square-neck bolts M6x35 6
10
Round-head square-neck bolt M6x40 1
11
Flat-head screw 3
12
Short pan-head screw 4
13
Long pan-head screw 4
14
Clamping knob 2
15
Starter pin 1
16
Level screws 4
17
Small nut 8
18
Spring washer 8
19
Small washer 16
20
Ellipse-shaped washer 2
21
Tabletop insert w/ 1 1/4" Dia. Hole 1
22
Tabletop insert w/ 1 7/8" Dia. Hole 1
23
Tabletop insert w/ 2 1/8" Dia. Hole 1
