MasterCraft 054-6902-0

DIGITAL PLUNGE ROUTER - 054-6902-0DIGITAL PLUNGE ROUTER - 054-6902-0
41 42
No. PartNo. Description No. PartNo. Description
1 5610220000 Screw 27 3402387000 Magnet Ring
2 3321132000 Rear Cover 28 3700249000 Washer
3 3125682000 Adjusting Knob 29 3121049000 Rubber Spring
4 3121518000 Transparent Cap 30 5700008000 Ball Bearing
5 3125683000 Knob 31 2750184000 Rotor
6 3125686000 Window Display 32 2823021000 LED Holder Assembly
7 5610017000 Tapping Screw 33 3421186000 Motor Housing
8 4890638000 Speed Adjustor 34 5700056000 Ball Bearing
9 5620017000 Screw 35 5610076000 Tapping Screw
10 3120537000 Brush Cover 36 5630179000 Nut
11 4960019000 Carbon Brush Assembly 37 3551635000 Spindle Lock
12 2800005000 Brush Holder Assembly 38 3660174000 Stop Spring
13 5610106000 Tapping Screw 39 5620061000 Screw
14 5610059000 Screw 40 3421190000 Spindle Lock Cover
15 2823115000 Switch Assembly 41 5620069000 Screw
16 3122851000 Seal Ring 42 2823121000 Collet Assembly
201 4810002000 Power Cord Assembly 43 3660512000 Compression Spring
17 4930008000 Sleeve 44 5620032000 Screw
18 4930038000 Receptacle 45 3123435000 Adjusting Knob
19 3121064000 Cord Guard 46 5650014000 Plain Washer
20 3122798000 Cord Anchorage 47 3660313000 Spring
21 3125685000 Middle Housing 48 3550083000 Depth Adjusting Bolt
22 2822038000 Inner Wire Assembly 49 3550913000 Depth Stop Bar
23 2822039000 Inner Wire Assembly 50 3121634000 Depth Indicator
24 2740118000 Stator 51 3121639000 Cover
25 5610049000 Tapping Screw 52 3402338000 Lock Bolt
26 3125687000 Fan Baffle 53 5660018000 Circlips
202 2823114000 Rotor Set 54 3123498000 Cap
Ifanypartsaremissingordamaged,orifyouhaveanyquestions,
pleasecalltheToll-freeHelpline,at1-800-689-9928.
No. PartNo. Description No. PartNo. Description
55 5630016000 Nut 72 5700046000 Steel Ball
56 3123497000 Cover 73 3660030000 Spring
57 2823224000 Plunge Frame 74 5660319000 E Ring
58 3121635000 Handle 75 5650023000 Washer
59 5620024000 Screw 76 3550929000 Bolt
60 5640045000 Bolt 77 3122923000 Base Plate
61 3660254000 Torsion Spring 78 5620074000 Screw
62 3420398000 Plunge-Depth Locking Lever 79 2823223000 Mounting Assembly
63 5620040000 Screw 80 3123344000 Chip Shield
64 5650007000 Spring Washer 81 3402220000 Depth Adjusting Lever
65 5630015000 Nut 82 2823125000 Collet Assembly
66 2823122000 Lever Assembly 83 5620353000 Screw
67 3123581000 Bellows Seal 84 3123454000 Vacuum Adapter
68 3660166000 Spring 85 3123500000 Support Plate
69 5620103000 Screw 86 3402471000 Wrench
70 3700078000 Wave Washer 87 2823015000 Parallel Guide
71 3420387000 Turntable
Ifanypartsaremissingordamaged,orifyouhaveanyquestions,
pleasecalltheToll-freeHelpline,at1-800-689-9928.
PARTS LIST
PARTS LIST
