FIXED-BASE ROUTER - 054-6908-8FIXED-BASE ROUTER - 054-6908-8
35 36
No. Part No. Description No. Part No. Description
1 5610220000 Screw 31 5700056000 Ball Bearing
2 3123916000 Rear Cover 32 3420356000 Motor Housing
3 3121518000 Transparent Cap 33 3520227000 Gear Rack
4 5610017000 Screw 34 5620062000 Screw
5 4900046000 PCB Assembly 35 3550592000 Spindle Lock
6 4540017000 Power Supply Indicator 36 5660005000 E-Ring
7 5620017000 Hexagon Socket Screw 37 3660174000 Stop Spring
8 5610106000 Tapping Screw 38 5630179000 Nut
9 3122798000 Cord Anchor 39 5630187000 Collet Nut
10 5610059000 Thread Forming Screw 40 3550721000 Collet
11 3120537000 Brush Cover 41 3121637000 Chip Shield
12 2800005000 Brush Holder Assembly 42 5620024000 Hexagon Socket Screw
13 4960019000 Carbon Brush Assembly 43 3320631000 Right Handle
14 3122851000 Seal Ring 44 5670040000 Located Pin
15 4870073000 Switch 45 3420396000 Mounting
16 3121494000 Middle Housing 46 3400189000 Locking Bolt
17 3121050000 Cord Guard 47 3320632000 Left Handle
18 4810002000 Power Cord & Plug 48 3121648000 Button
19 3123926000 Bearing Holder 49 3550579000 Gear Shaft
20 3121049000 Rubber Spring 50 3520141000 Gear
21 3700249000 Washer 51 3520147000 Locking Gear
22 5700008000 Ball Bearing 52 3550615000 Worm
23 2740116000 Stator 53 5620033000 Screw
24 5610048000 Tapping Screw 54 3660167000 Spring
25 2822039000 Internal Wire Assembly 55 5630015000 Prevailing Torque Hexagon Nut
26 2822038000 Internal Wire Assembly 56 3700848000 Plate
27 2750719000 Rotor 57 5660003000 E-Ring
28 3121495000 Fan Baffle 58 3420395000 Clamping Lever
29 5620040000 Screw 59 5620332000 Screw
30 2820887000 LED Holder Assembly 60 3550596000 Locking Pin
If any parts are missing or damaged, or if you have any questions,
please call the Toll-free Helpline, at 1-800-689-9928.
No. Part No. Description No. Part No. Description
61 5620041000 Screw 70 5650015000 Spring Washer
62 3121646000 Adjusting Knob 71 5650013000 Plain Washer
63 3121647000 Indicator 72 3703591000 Parallel Guide
64 5650172000 Wave Washer 73 3550683000 Guiding Rod
65 3550613000 Shaft 74 3550560000 Collet
66 5630003000 Hexagon Nut 75 3700807000 Wrench
67 3122924000 Mounting Plate 76 3122784000 Vacuum Adaptor
68 5620049000 Screw 77 5620040000 Screw
69 5620050000 Screw
If any parts are missing or damaged, or if you have any questions,
please call the Toll-free Helpline, at 1-800-689-9928.
