23
ASSEMBLY
GROUNDING
Your generator must be properly connected to an appropriate ground to help prevent electric
shock.
A ground terminal connected to the frame of the generator has been provided (see Controls and
Features for terminal location). For remote grounding, connect a length of heavy gauge
(12 AWG minimum) copper wire between the generator ground terminal and a copper rod driven
into the ground. We strongly recommend that you consult with a qualified electrician to ensure
compliance with local electrical codes.
Neutral Floating*
– Neutral circuit IS NOT electrically connected to the frame/ground of the generator.
– The generator (stator winding) is isolated from the frame and from the AC receptacle
ground pin.
– Electrical devices that require a grounded receptacle pin connection will not function if
the receptacle ground pin is not functional.
Neutral Bonded to Frame*
– Neutral circuit IS electrically connected to the frame/ground of the generator.
– The generator system ground connects to the lower frame cross-member below the
alternator. The system ground is connected to the AC neutral wire.
*See your Specifications section for specified type of grounding.
WARNING!
• Failure to properly ground the generator can result in electric shock.
