PARTS LIST
     
51 Dust connection tube 1 81 Spring washer 4
52 Fixed guard 1 82 Screw 17
53 Bearing 1 83 Clamp rod 1
54 Brand label 1 84 Mitre pointer 1
55 Circlip 1 85 Table 1
56 Big gear 1 86 Press plate 1
57 Woodruff key 1 87 Flat washer 1
58 Spindle 1 88 Inner hex screw 1
59 Front cover 1 89 Location pin sleeve 1
60 Inner ange 1 90 Inner hex screw 2
61 Blade 1 91 Screw 1
62 Out ange 1 92 Shoulder screw 1
63 Hex reverse screw 1 93 Connection rod 1
64 Hex bolt 1 94 Wave washer 4
65 Guard support 1 95 Bevel pointer 1
66 Torsional spring 1 96 Laser support 1
67 Screw 1 97 Laser 1
68 Screw 3 98 Angle location pin 1
69 Moving guard 1 99 Inner hex screw 8
70 Laser warning label 2 100 Spring washer 4
71 Cutting slot plate 1 101 Shoulder screw 2
72 Flat washer 6 102 Flat washer 2
73 Locknut 2 103 Stop plate 1
74 Inner teeth washer 2 104 Seal ring 1
75 Guard roller 2 105 Location pin knob 1
76 Clamp screw 1 106 Rotation shaft 1
77 Lock screw 1 107 Angle lable 1
78 Connection rod 1 108 Support 1
79 Clamp press plate 1 109 Lock pin 1
80 Flat washer 7 110 Transmission plate 1
PARTS LIST
     
111 Hexagon screw 1 132 Screw 2
112 Sliding support cover 2 133 Stop plate 1
113 Buffer ring 2 134 Wave washer 1
114 Sliding lock knob 1 135 Lock piece 1
115 Compress spring 1 136 Hex nut 1
116 Straight bearing 3 137 Screw 1
117 Cord hold ring 1 138 Spring 1
118 Screw 4 139 Mitre location block 1
119 Hex spanner 1 140 Mitre location rod 1
120 Hex bolt 1 141 Compress spring 1
121 Bevel lock knob 1 142 Table support foot 1
122 Locknut 1 143 Mitre handle 1
123 Flat washer 2 144 Extension wing 2
124 Flat washer 1 145 Lock handle cover 1
125 Guide rod support 1 146 Mitre scale label 1
126 Plastic handle 1 147 Base 1
127 Guide rod 2 148 Locknut 1
128 Left fence 1 149 Dust bag 1
129 Right fence 1 150 Spring ring 1
130 Lock knob 2 151 Crank arm 1
131 Screw 2
