KEY PARTS DIAGRAM
17 Dust bag
18 Blade
19 Motor
20 Spindle lock
21 Lock-down pin
22 Slide carriage lock knob
23 Bevel lock knob
24 Bevel scale
25 Table
26 Mitre scale
27 Hex wrench
28 laser
WARNING!
Your saw should NEVER be connected to the power source when you are assembling parts,
making adjustments, installing or removing blades, or cleaning, or when it it not in use.
Disconnecting the saw will prevent accidental starting, which could cause serious personal injury.
WARNING!
Do not allow familiarity with the mitre saw to cause a lack of alertness. A fraction of a second of
carelessness is enough to cause severe injury.
KEY PART DIAGRAM
KEY PARTS DIAGRAM
NOTE:
Before attempting to use your saw, familiarize yourself with all of the operating features and
safety requirements.
1 Switch handle
2 On/Off trigger switch
3 Upper blade guard
4 Lower blade guard
5 Base
6 Table insert
7 Mitre handle
8 Mitre stop locking lever
9 Positive mitre stop
10 Mounting hole
11 Handhold for transportation
12 Extension wing
13 Work clamp
14 Upper fence
15 Lower fence
16 0° stop pin
WARNING!
Carefully remove the tool and any accessories from the box. Make sure that all items listed in
the packing list are included. Inspect the tool carefully to make sure that no breakage or damage
occurred during shipping.
WARNING!
Do not discard the packing material until you have carefully inspected and satisfactorily operated
the tool.
25
23
18
19
20
17
27
21
22
24
26
28
1
6
7
8
2
10
4
3
5
9
11
12
13
16
14
15
