OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
WARNING!
Risk of bursting. Too much air pressure causes a hazardous risk of bursting. Check the manufacturer’s
maximum pressure rating for air tools and accessories. The regulator outlet pressure must never exceed
the maximum pressure rating.
If the pump has been transported or turned upside down (even partially), allow the pump to sit in a normal,
upright position for approximately 10 minutes before starting.
High temperatures are generated by the electric motor and the pump. To prevent burns or other injuries,
DO NOT touch the air compressor while it is running. Allow it to cool before handling or servicing. Keep
children away from the air compressor at all times.
WARNING!
WARNING!
CAUTION!
Escaping air and moisture can propel debris that may cause eye injury. Wear safety goggles when opening the
drain valve.
WARNING!
To avoid personal injury, always shut off and unplug the unit, and relieve all air pressure from the system before
performing any service on the air compressor.
Risk of unsafe operation. Unit cycles automatically when power is on. When performing maintenance, you may be
exposed to voltage sources, compressed air or moving parts. Personal injuries can occur. Before performing any
maintenance or repair, disconnect power source from the compressor and bleed off all air pressure.
WARNING!
Before each start-up
1. Set the ON/OFF switch (B) to the OFF position.
2. Turn the air pressure regulator (D) knob counter-clockwise until it stops.
3. Attach hose and accessories.
How to start
1. Close the tank drain valve (H). Plug in the power cord (J).
2. Set the ON/OFF switch (B) to the ON position and allow the tank pressure to build.
Motor will stop when tank pressure reaches cut-out pressure.
3. Turn the air pressure regulator knob clockwise until desired pressure is reached.
Shut down procedure
1. Set the ON/OFF switch (B) to the OFF position.
2. Unplug the power cord (J).
3.
Reduce the pressure in the tank through the outlet hose. Pulling the safety valve
ring (C) and keeping it open will also reduce the pressure in the tank.
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 058-1893-2 | contact us 1-800-689-9928
B
C
J
H
J
D
B
