Picture 2
For best results with tongue and groove flooring, the distance between the bottom of the Spacer Wheel
and the tip of the Drive Guide should be the same as the distance between the top surface of the floor
and the top of the step (tongue). This will allow the nail to be inserted in the proper location for
maximum security and ease of installation.
If the distance between the top surface of the floor and the top of the step (tongue) is less than 10 mm,
you can turn the Spacer Wheel to adjust the Drive Guide location.
Ensure that the Spacer Wheel sits flush with the floor surface and the Driver Guide fits snugly
in the corner of the tongue and the riser before driving any nails.
x When used properly, the air-powered flooring stapler/nailer will position the boards snugly and
fasten them with one action.
x Check and adjust the pressure in order to ensure that it is within the appropriate operating range.
x TEST THE STAPLER ON A SAMPLE PIECE OF FLOORING BEFORE STARTING.
Operation
x Hold the handle, and lift the flooring stapler/nailer into place.
x Continue to hold the handle, and swing the mallet, striking the top end of the “whack-cap” with the
rubber face of the mallet.
Riser
Step (Tongue)
