MasterCraft 058-8198-6 - Specifications; Fastener and Magazine Specifications; Tool Performance and Physical Specs

Table of Contents
Page
Specifications ............................................................................................................................................................... 2
Important Safety Instructions....................................................................................................................................... 3
Know Your Nailer ......................................................................................................................................................... 5
Before You Start .......................................................................................................................................................... 6
Operating Instructions.................................................................................................................................................. 9
Maintenance................................................................................................................................................................11
Troubleshooting.......................................................................................................................................................... 12
Exploded View ........................................................................................................................................................... 14
Parts List..................................................................................................................................................................... 15
Warranty ..................................................................................................................................................................... 16
Specifications
Magazine capacity ....................................................................................................... 60 staples/120 nails
T& L-cleat nail size range .................................................................... 1 1/2 - 2” (38 – 50 mm) (16-gauge)
Staple size range …………………………………………………….38mm(1-1/2’’)–50mm(2’’) (15.5 gauge)
Staple crown ........................................................................................................................ 1/2” (12.7 mm)
Recommended operating pressure .............................................................. 6.3 to 8.3 Bar (90 to 120 PSI)
Maximum pressure .......................................................................................................... 8.3 Bar (120 PSI)
SCFM requirement................................................................................................................6.36 @ 90 PSI
Air inlet .............................................................................................................................. 1/4” (7 mm) NPT
Dimensions .............................................................................. 21” x 19 1/4” x 3 1/4” (530 x 500 x 92 mm)
Weight............................................................................................................................. 12 lb 2 oz (5.5 kg)
