Operating Instructions — Using the Air-powered Flooring
Stapler/Nailer
The safety nose must be in contact with the workpiece before
activating the tool. Do not operate the tool if there are no fasteners
loaded. Doing so may damage the tool. Do not fire fasteners into the
air. Doing so may cause injury to the operator or others, and may
damage the tool.
Preparation
x When installing hardwood flooring, position the flooring according to the manufacturer’s
specifications.
x This air-powered flooring stapler/nailer can be used for various thicknesses of flooring.
x Ensure that the Drive Guide is properly aligned to your target. The height of the Drive Guide
and nail depth is adjustable by turning the Spacer Wheel. For detailed information, please see the
below pictures:
Picture 1
The original manufacturer Spacer setting between the bottom of the Spacer Wheel and the tip of the
Drive Guide is 10 mm.
Spacer
Wheel
Drive Guide
