PARTS LIST
22
AIR-POWERED DUAL-ACTION SANDER 058-9325-8
If any parts are missing or damaged, or if you have any questions, please call 1-800-689-9928.
No. Description Qty. No. Description Qty.
1 Sanding pad 1 24 Cylinder 1
2 Handle grip 1 25 Pin 3 X 7 1
3 Snap ring 1 26 Front cylinder cover 1
4 Bearing washer 1 27 Nut 1
5 Dust-proof mat 1 28 O-ring 9 X 2 1
6 Main shaft 1 29 Spring 1
7 Bearing 6001zz 2 30 O-ring 6.7 x 1.8 1
8 Drive shaft 1 31 O-ring 2.5 X 1.5 1
9 Woodruff key 1 32 Valve pin 1
10 Front cover washer 1 33 O-ring 3 x 1 1
11 Collar 1 34 Regulator 1
12 O-ring 37.5 X 3.55 1 35 O-ring 10 X 1.5 3
13 Main housing 1 36 Snap ring 1
14 Label 1 37 Air inlet 1
15 Housing edge 1 38 Bolt 1
16 Collar 1 39 Split washer 2
17 Bolt 1 40 Trigger pin 1
18 Gasket 1 41 Trigger 1
19 Bearing 6000Z 2 42 Tee coupling 1
20 Back cylinder cover 1 43 Air outlet plug 1
21 Rotor 1 44 End cap 1
22 Rotor blade 5 45 Dust cover 1
23 Pin 3 X 14 1
To Next Page
