MAINTENANCE
Note: Wash the air cap (1) carefully without
causing any damage to its air hole as it will
affect the spraying pattern. Never use a steel
wire or wire brush for cleaning. When the air
hole is clogged, clean it using a wooden
toothpick (2) (fig C).
Note: When it is hard to get rid of the stuck
paint, soak the cap in lacquer thinner and
wash it again.
CAUTION!
POTENTIAL HAZARD THAT MAY RESULT IN MODERATE INJURY OR DAMAGE TO
EQUIPMENT.
• Incomplete cleaning could cause function failures and a degradation of the tool.
Failure to comply may result in moderate injury or damage to equipment.
POTENTIAL HAZARD THAT COULD RESULT IN SERIOUS INJURY OR LOSS OF LIFE.
WARNING!
• Do not use metal or other objects that could damage the holes in the nozzle
and cap.
• Never immerse the spray gun completely in solvent.
• Do not use components or parts that are not recommended. Failure to comply
could result in serious injury or loss of life.
CAUTION!
• Ensure that the needle is removed before disassembling the nozzle to avoid
damage to the nozzle closure housing. Failure to comply may result in
moderate injury or damage to equipment.
POTENTIAL HAZARD THAT MAY RESULT IN MODERATE INJURY OR DAMAGE TO
EQUIPMENT.
MAINTENANCE
• Remove the remaining paint by pouring it into another canister.
• Disassemble the Air-powered Gravity-feed Spray Gun. Ensure that the needle is
removed before disassembling the nozzle to avoid damage to the housing of
the nozzle closure.
• Clean all the paint passages, nozzle, and other components using a brush
soaked in cleaning solvent.
• Reassemble the spray gun and spray a small quantity of solvent to remove any
residues in the paint passages.
MAXIMUM SERVICE INTERVAL
