MasterCraft 068-0002-6

21. Install Mounting Straps
(Part 60)
A: Remove two Screws (Part 16)
from the Pegboard Support Bars
(Part 18-A and 18-B). These
screws will no longer be used.
B: Attach the Mounting Straps (Part
60) to the sides of Pegboard (Part
18-A and 18-B), using two
Washers (Part 27) with two Screws
(Part 61) and Screwdriver (Part 21) to tighten.
C: Drill two holes in the wall with a 5/16" drill bit, and
insert two Wall Anchors (Part 55-A) into the holes.
D: Attach the free end of the Mounting Straps (Part 60) to
the wall using two Screws (Part 55), two Washers (Part
27-B) and Screwdriver (Part 21) to tighten.
Stainless Steel Maintenance:
These parts have an fingerprint-resistant finish. Do not use traditional stainless
steel cleaners on this unit. Lightly wipe off once a month with clean warm water
and a soft cloth (preferably a microfibre cloth). This is the safest formula to prevent
new stains from appearing over time and manage unwanted fingerprints or grease
marks. Remember to always wipe in the direction of the surface grain (NEVER
ACROSS) and always use a lint-free cloth. Once the surface is clean, thoroughly
wipe dry with a soft, absorbent cloth.
16
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0002-6 | contact us 1-800-689-9928
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
Fig. Y
60
55-A
27-B
55
61
27
