MasterCraft 068-0002-6

15
ASSEMBLY INSTRUCTIONS
19. Install Pegboard (Part 28)
Attach the Pegbord (Part 28) to the
support bars by lining up the screw
holes, and use six Screws (Part 16)
and Screwdriver (Part 21) to
tighten (Fig. W).
20. Install Top Cantilever Shelf
(Part 29)
A: Please take off left and right
back side of Top Cantilever Shelf
(Part 29) screws, total four screws
(Part 16).
B: Attach Top Cantilever Shelf (Part
29) to the top of the Pegboard
Support Bars by lining up the
screw holes, and using the
removed four Screws (Part 16) and
Screwdriver (Part 21) to tighten.
Attach Top Cantilever Shelf (Part
29) to the top of the Pegboard (Part
28) using two Screws (Part 17) and
Screwdriver (Part 21) to tighten.
Put the Mat (Part 30) into the Top
Cantilever Shelf (Part 29) (Fig. X).
Note: Do not fully tighten the screws. This
will help you make any adjustments for
alignment later.
Fig. W
Fig. X
