Boats may also be equipped with towers, which
may include stereo speakers, and/or lights.
Bow light
Bow cleat
Stereo CD Player
(inside glove box,
where equipped)
Sirius Satellite Radio
(where equipped)
Glove box
Battery
(located in void
beneath observer seat)
MTS Ballast System
(where equipped,
beneath observer seat)
Hand-held fire extinguishers
(beneath observer seat)
Amp (where equipped,
beneath observer seat)
iPod interface
(where equipped)
Ski pylon
Center drain plug
(inside engine compartment)
Fire port
Ballast vent
Fuel tank filler
Stern cleat
(where equipped)
Swim platform
Engine exhaust
(two below swim platform)
Transom rail with tow eye
(where equipped)
Transom drain plug
(center beneath swim platform)
Bow filler cushion
(where equipped)
Folding walk-thru seat
Built-in cooler
Bilge thru-hull outlet
Adjustable mirror
Bow cleat
Circuit breaker panel
(on kick panel
beneath instrument panel)
Instrument panel
(details elsewhere in this section)
Subwoofer (where equipped)
Steering wheel
Shift-throttle control
Engine compartment
Rear Ballast System fill
(where equipped)
Stern light receptacle
(if equipped with tower,
the light will be in
center aft of tower)
Stern cleat
(where equipped)
Ballast thru-hull vent
Shower wand & switch
(where equipped, inside
storage compartment)
Underwater lights
(two where equipped
under swim platform)
Transom stereo remote
(where equipped)
Under-platform ladder
(where equipped)
Storage space is located:
Under observer’s seat
Under bow seating
Under aft seating
Under aft sun pad
2013 MasterCraft Owners Manual • Guide to Individual Models • Page 2-9
