FEATURES
01. Bow hatch (where equipped)
02. Drop-in walk-thru door
03. Circuit breaker panel, including battery ON-
OFF switch (side panel, walk-thru)
04. Bilge thru-hull outlet
05. Navigation light
06. Bow cleat (where equipped)
07. Adjustable mirror
08. Instrument panel (details follow)
instrument panel)
09. Steering wheel
10. Shift-throttle control
11. Fire suppression unit manual override
12. Drain plug
13. In-floor storage compartment
14. Engine compartment
15. Aft seating (where equipped)
16. Fuel tank filler
17. Stern cleat (where equipped)
18. Aft storage compartment
19. Transom rail with tow eye (where equipped)
20. Bow seating (where equipped)
21. Heater (where equipped)
22. Sirius Satellite Radio (where equipped)
23. Navigation light
24. Stereo CD Player (inside glove box,
where equipped)
25. iPod interface (where equipped, inside
glove box)
26. Glove box
27. Bow cleat (where equipped)
28. MTS Ballast System (where equipped,
beneath observer seat)
29. Hand-held fire extinguishers (beneath
observer seat)
30. Amp (where equipped, beneath observer
seat)
31. Folding walk-thru seat
32. Ski pylon
33. Automatic fire extinguisher (inside engine
compartment)
34. Stern light receptacle (if equipped with
tower, the light will be in center aft of tower)
35. Aft seating (where equipped)
36. Stern cleat (where equipped)
37. Battery (beneath storage door)
38. Aft storage compartment
39. Engine exhaust (two below swim platform)
40. Swim platform
SPECIFICATIONS
Length of Boat 20’0”
Width Amidship 96”
Boat Weight 3,300 lbs.
Length of Boat w/Platform 21’ 6”
Towing Length 25’ 11”
Towing Width 100”
Fuel Capacity 25 gallons
Maximum Capacity 7 people
or 1,341 lbs.
Bow: 2 people or 300 lbs.
Weight must be evenly distributed.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, port and starboard sun pads.
