2021 OWNERS MANUAL / 308
CONVERTIBLE CENTER REAR SEAT
Models
Optional on all X, XT and XStar models.
Purpose
Allow the option of occupants to sit forward facing, rear facing or
create a center cockpit sunpad.
Location
Aft section of the cockpit.
Operation
The seat has a sliding/locking pivot connecting the seat back to the
seat cushion.
Forward to Rear Facing and vice versa: Lift sharply up on the handle
at the top of the seat back to lift o the “Lock” position. Hold the
handle while lifting the seat back up and away from its current
position. The seat cushion will then lift and rotate. Continue pulling
forward until the seat cushion rotates past vertical. Then lower the
handle and press the seat back down toward the cockpit floor as the
seat cushion comes to rest 180 degrees from its previous position.
This will reengage the seat back “Lock”
Rear Facing to Sunpad: When the seat is in the rear facing position,
lift sharply up on the handle at the top of the seat back to lift o the
“Lock” position. Hold the handle while rotating the seat back toward
the bow of the boat. The seat back will rotate and lay down on braces
in the cockpit to create a full sunpad.
Sunpad to Rear Facing: Lift and rotate the handle on the seat back.
When the seat back is vertical, press the seat back down toward the
cockpit floor as the seat cushion comes to rest 180 degrees from its
previous position. This will reengage the seat back “Lock”.
REMOVABLE REAR SEATS
