mastercraft 2010 ow n e r ’s m anual • page 4-1
prostar 190
01
28
26
25
22
21
20
15
12
04
05, 06, 07, 08, 09
11
18
17
16
19
03
02
13
24
33
29
30
32
35
36
01 Bow light
02 Bow cleat
03 Stereo CD Player
(inside glove box, where equipped) Sirius
Satellite Radio
(where equipped)
04 Glove box
05 Battery
(located in void beneath observer seat)
 06 MTSBallastSystemll(where equipped, beneath observer seat)
 07 Hand-heldreextinguishers(beneath observer seat)
08 Amp (where equipped, beneath observer seat)
09 iPod interface (where equipped)
10 Center drain plug
11 Ski pylon
12 Fire port
 13 Fueltankller
14 Stern cleat
15 Ballast vent
16 Swim platform
17 Engine exhaust
(two below swim platform)
18 Transom rail with tow eye (where equipped)
19 Transom drain plug (center beneath swim platform)
20 Under-platform ladder (where equipped)
21 Transom stereo remote (where equipped)
22 Underwater lights (two where equipped under swim platform)
23 Shower wand & switch/Slick Boot wand & switch (where
equipped, inside storage compartment)
24 Ballast thru-hull vent
25 Stern cleat
26 Stern light receptacle
(if equipped with tower, the light will be in
center aft of tower)
 27 RearBallastSystemll(where equipped)
28 Engine compartment
29 Shift/throttle control
30 Steering wheel
31 Instrument panel (details elsewhere in this section)
32 Subwoofer (where equipped)
33 Circuit breaker panel (on kick panel beneath instrument panel)
34 Bow cleat
35 Bilge thru-hull outlet
36 Adjustable mirror
37 Built-in cooler
Boats may also be equipped with towers, which may include
stereo speakers, lights and/or tower-mounted mirror
Storage space is located:
Under observer’s seat (including into bow)
Under aft seating
Under aft sun pad
10
14
23
27
31
34
37
