model no. SC20BST | contact us 1-800-689-9928
INSTALL THE EDGING WHEEL
(fig 3)
1. Align two slots on the wheel with the metal plate
on the trimmer head, and then fully insert the
wheel onto the metal plate.
2. To remove the wheel, press and hold the button
on the wheel, and then pull out the wheel in the
“Detach” direction.
ADJUST THE AUXILIARY HANDLE
(fig 4)
1. Press the handle-unlock button and the left button
together, slide the auxiliary handle onto the two
buttons and then release the buttons to lock the
handle.
2. Rotate the auxiliary handle to the most comfortable
and balanced position.
3. Then release the handle-unlock button. Raise or
lower the auxiliary handle to make sure it is fixed
firmly.
OPERATING INSTRUCTIONS
fig 3b
Detach
Button
fig 3a
Slots
Metal
plate
Wheel
fig 4
Auxiliary handle
Handle-unlock
button
Left button
