2016 OWNERS MANUAL / 0259
Lowering and Raising the ZFT5 Tower
The ZFT5 tower operates under hydraulic power. The tower is con-
trolled by a switch located below the shift/throttle control on the
driver’s armrest. The tower will stop raising or lowering at any point
at which the operator releases the switch. However, the ZFT5 tower
should NEVER tow individuals at any position other than full upright
(where the tower will lock automatically).
When operating the ZFT5 tower, individuals should take care to
keep all body parts, especially fingers, away from hinge areas.
The towers do not have sensors to stop movement if anything
becomes pinched as the hinges move the tower up and down.
Skiing, wakeboard or any type of towing behind all towers should
occur only with the tower in the full, upright and locked position.
Failure to do so could result in serious injury or death.
In over-the-road transit, the adjustable towers should be only full
upright or fully lowered to avoid potential damage to the tower and/
or boat. NXT / Prostar / ZFTO - Only in the up position.
Always ensure that there are no people, power lines nor objects in
the way when raising and lowering the tower. Individuals and their
limbs may be subject to injury if caught in the path of the tower.
Special Attention
MasterCraft has carefully determined the maximum amount of ac-
cessories and total weight that the tower can safely hold. Ignoring
this information could result in injury to the boat operator and/or
passengers.
