137
/
2023 OWNER’S MANUAL
7” TOUCHSCREEN (PV700):
NAVIGATION AND OVERVIEW
Navigation within the 7” Touchscreen is controlled via touch
commands. The information displayed onscreen varies depending
on the operating mode selected (Drive or Tow). Regardless of the
mode selected, certain information is displayed at all times. The
screen always presents battery charge, water depth, engine hours,
water/air temperature, and time at the top of the display.
Note that boats equipped with the PV700 feature a suite of gauges
that present operating information onscreen, including speed,
RPM, fuel level, oil pressure, and engine temperature.
Operating Modes
The PV700 is organized around two main on-water activities:
driving from place-to-place and towing riders. To correspond with
these activities, the PV700 features two primary operating modes
(Drive and Tow), plus three Tow sub-modes (Surf, Wake and Ski).
• Drive Mode displays basic operating information for cruising.
From Drive Mode, you can quickly adjust speed, tabs,
and ballast.
• Tow Mode is broken down into three sub-modes: Surf, Wake,
and Ski. Factory-loaded profiles for ballast, speed, and tab
configurations are easy to select and modify from each sub-
mode. Each sub-mode features custom profile creation.
CARE AND MAINTENANCE
General maintenance is not required; however, a soft cloth can
be used for cleaning the unit. Glass cleaner or alcohol can also be
used to clean the glass portion of the display. Do not use harsh or
abrasive cleaners on the unit.
Avoid contact between sharp or hard objects and the video
screens, as this can result in scratches or other permanent marks
on the screen. Clean only with a soft cloth, using glass cleaner or
rubbing alcohol only. Never use harsh or abrasive cleaners on the
unit, as this may result in damage to the unit that is not covered
under warranty.
