2023 OWNER’S MANUAL
/
138
DRIVE MODE
Drive mode displays basic operating information for cruising
around your body of water. In Drive Mode, quickly fill or empty
ballast, adjust tab positions, and activate speed control.
Drive Mode is the default setting when the system first powers on.
Drive Mode Screen:
Outside
Temp
Water
Temp
Battery
Voltage
Cruise
ON/OFF
Time
Water
Depth
Cruise Set
Speed
Home
Media
Audio Zones
Lights
Heaters
Settings
Triple + Single
Tab AutoLaunch
Control
Tab Controls
Tow Controls
Increase/Reduce
Speed
Fill/Empty All
Ballast Tanks
Fill/Empty
Ballast
Tanks
Stereo
Controls
Profiles
To switch between modes, use the tabs located at the bottom of
the touch display. Touch DRIVE to access Drive Mode.
Touch SURF, WAKE, or SKI to access one of the Tow Mode variants.
Note that operators cannot switch between modes while
the throttle is in gear (forward or reverse).DRIVE MODE
