2023 OWNER’S MANUAL
/
282
To deploy the Z6, Z8 or Z10 Bimini
For balance, it is suggested that operators have an additional
person assist when raising or lowering a bimini top.
1. Unzip and remove the bimini boot cover
2. Unclip all clips securing the bimini legs to one another
3. Unfold to deploy the bimini. It folds forward, away from the tower
4. Zip all of the zippers on the af portion of the canvas around the
forward most tower tube
5. Buckle all straps around the tower loosely
6. Fully extend the bimini legs and ensure that they are locked
into place
7. Tighten all straps and buckles around the tower so that the
canvas is stretched tightly around the tower.
Collapsing the bimini is the opposite of deploying it:
1. Unlock the bimini legs and let them fold forward loosely
2. Loosen and unclip all buckles around the tower tubes
and supports
3. Unzip all zippers around the tower tubes
4. Fold the bimini and canvas up to the tower
5. Use the gray leg clips to keep the bimini legs locked together
6. Cover bimini with the protective boot, then zip the boot around
the canvas
