297
/
2023 OWNER’S MANUAL
HEAD AND TOILET SYSTEM
Toilet system start-up
1. Turn on fresh water pump switch at the helm side panel.
2. Press “Flush” switch and hold for at least 10 seconds.
3. Toss several sheets of toilet paper into bowl and repeat cycle. The
bowl should completely clear.
Normal flushing
FLUSHING TOILET
Model
X26, as an option
Purpose
The on-board head provides convenience
for longer outings.
Location
The head is located forward of the observer seat, accessible
through a door that opens into the walk-thru area to the bow.
Operation
This boat is equipped with an Dometic Masterflush electric
macerating toilet. The Masterflush toilet has a rugged glass filled
nylon twin impeller that instantly draws in the euent into the
macerating chamber where the waste is pulverized by a 10-blade
stainless steel cutting wheel and ejects it into the waste tank
on the starboard side of the boat via a short run of premium
sanitation hose.
Press “Flush” switch (bottom switch) down
and hold until waste drains from toilet
bowl (about 10 – 20 seconds). This switch
activates a macerator pump that siphons
water and waste from the bowl, macerates,
and propels the euent to the discharge
line/holding tank.
Do not flush waste with “Dry Bowl” Switch! To maintain proper
cleanliness and operation of the toilet and macerator pump, water
should be used with every flush.
NOTE: Make sure all guests understand toilet operation before use.
