Page 7
OVERVIEW
SPECIFICATIONS
Motor 20 Volt DC
Switch VSR (Variable Speed Reversible)
No-load speed LO: 0-300 RPM / HI: 0-1300 RPM
Hammer LO: 0-3900 BPM / HI: 0-16900 BPM
Clutch 24 position
Chuck 1/2” (13mm), ratcheting, single-sleeve keyless
Max torque 480 in. lbs.
Hammer Drill weight (without battery) 3.06 lbs.
Battery voltage 20 Volt DC
Charger input 120-Volts, 60Hz, AC only
Optimum charging temperature 32°F (0°C) – 122°F (50°C)
Torque adjustment ring
Hammer/screw/drill mode selection ring
Ratcheting keyless chuck
LED worklight
Battery release button
Battery pack
Two-speed gearbox switch
Auxiliary handle
Power display
Power display
button
Trigger switch
