MasterForce 241-0836 - Parts List

20
21
Parts List
No. Part Name Qty
Motor Unit:
1 Screw 2
2 Rear Cover 1
3 Screw 2
4 Transparent Cap 1
5 PCB Plate 1
6 Seal Ring 1
7 Switch 1
8 Screw 2
9 Taping Screw 2
10 Cord Anchorage 1
11 Power Indicator Light 1
12 Screw 2
13 Power Cord 1
14 Cord Guard 1
15 Bush Cover 2
16 Carbon Brush 2
17 Brush Holder 2
18 Middle Housing 1
19 Stator 1
20 Screw 2
21 Bearing Holder 1
22 Washer 1
23 Gasket 1
24 Bearing 1
25 Fan Baffle 1
26 Rotor 1
27 Depth Indicator 7
28 Depth Adjusting Bolt 1
29 Depth Stop Bar 1
30 Screw 2
31 Plunge Lock Lever 1
32 Slotted Set Screw 1
33 Wave Washer 1
34 Nut 2
35 Left Handle Cover 1
36 Hexagon Socket Screw 1
37 Spring Washer 2
38 Plain Washer 1
39 Left Handle 2
40 Plunge Frame 2
Fixed Unit:
41 Screw 2
42 Right Handle 1
43 Left Handle 1
No. Part Name Qty
44 Lock Bolt 5
45 Mounting 1
46 Chip Shield 1
47 Base Plate 1
48 E Ring 1
49 Spring 1
50 Lock Gear 1
51 Gear 1
52 Gear Shaft 1
53 Button 1
54 Shaft 1
55 Worm 1
56 Screw 1
57 Indicator Ring 1
58 Adjusting Knob 1
59 Screw 1
60 Screw 1
61 Lock Pin 1
62 Clamping Lever 1
63 Plate 1
64 Lock Nut 2
65 Screw 6
66 Washer 1
67 Located Pin 2
Plunge Unit:
68 Screw 1
69 Depth Adjusting Cap/ 1
70 ‘’O’’ Ring 1
71 Depth Stop Bar 1
72 Adjusting Pole 1
73 Depth Indicator 1
74 Screw 4
75 Left Handle Cover 1
76 Screw 2
77 Left Handle 1
78 Right Handle 1
79 Right Handle Cover 1
80 Cover 1
81 Circlips of Shaft 1
82 Spring Washer 1
83 Plunge Lock Lever 1
84 Torsion Spring 1
85 Bolt 1
86 Pin 1
87 Clamping Lever 1
88 Mitre Lock Bolt 1
89 Plunge Frame 1
