OVERVIEW
SPECIFICATIONS
Motor 80V Brushless
No-load speed 170 ± 5% RPM
Cultivating Path 10'' (25 cm)
Cultivating Depth 5'' (13 cm)
Weight (Without Battery) 29.3 lb. (13.3 kg)
The recommended ambient temperature range:
Item Temperature
Cultivator storage temperature range 32°F (0°C) - 113°F (45°C)
Cultivator operation temperature range 32°F (0°C) - 113°F (45°C)
Battery charging temperature range 39°F (4°C) - 104°F (40°C)
Charger operation temperature range 39°F (4°C) - 104°F (40°C)
Battery storage temperature range 32°F (0°C) - 113°F (45°C)
Battery discharging temperature range 32°F (0°C) - 113°F (45°C)
Handle bar
Safety lock button
Tine shield
Inner tine
Outer tine
Hitch pin
Bolt
Hitch pin
Wheel
assembly
