Page 9
ASSEMBLY
LINE TRIMMER CUT-OFF BLADE
The trimmer is equipped with a line trimming
cut-off blade on the guard. Replace the line
maintain best performance.
Adjusting the cutting swath
The trimmer is currently set at a 14 in. cutting
swath. To adjust to a cutting swath of 16 in.:
1. Remove the battery from the string
trimmer.
2. Remove both screws from the cut-off
blade with a Phillips screwdriver (not
included).
3. Rotate the cut-off blade 180°.
4. Replace both screws in the cut-off blade.
AUXILIARY HANDLE
1. Remove the knob from the handle.
2. Attach the auxiliary handle and lower
clamp on the shaft.
3. Set the auxiliary handle to a comfortable
position.
4. Put the bolt through the holes.
5. Tighten the auxiliary handle with the
knob.
FIG. 4
FIG. 3
