Page 10
ASSEMBLY
SHOULDER STRAP
1. Rotate the shoulder strap connection point
to the upward position.
2. Hook the shoulder strap to the shoulder
strap connection point.
THE BATTERY PACK
• If the battery pack or charger is damaged,
replace the battery pack or the charger.
• Stop the machine and wait until the motor
stops before you install or remove the battery
pack.
• Read, know, and follow the instructions in
the battery and charger manuals.
To install the battery pack
1. Align the lift ribs on the battery pack with
the grooves in the battery compartment.
2. Push the battery pack into the battery
compartment until the battery pack locks
into place.
3. When you hear a click, the battery pack is
installed.
To remove the battery pack
1. Push and hold the battery release button
(1).
2. Remove the battery pack from the
machine.
FIG. 6
FIG. 5
