MasterForce STB460 - Page 10

Page 9
To remove the attachment from the power
head
For removing or changing the attachment:
1. Stop the power head.
2. Remove the battery from the power head.
3. Loosen the attachment knob.
4. Push in the release button and twist the
shafts to remove and seperate ends.
ASSEMBLY
LINE TRIMMER CUT-OFF BLADE
The trimmer is equipped with a line trimming
cut-off blade on the guard. Replace the line
maintain best performance.
Adjusting the cutting swath
The trimmer is currently set at a 14 in. cutting
swath. To adjust to a cutting swath of 16 in.:
1. Remove the battery from the string
trimmer.
2.
blade with a Phillips screwdriver (not
included).
3.
4.
AUXILIARY HANDLE
1. Remove the knob from the handle.
2. Attach the auxiliary handle and lower
clamp on the shaft.
3. Set the auxiliary handle to a comfortable
position.
4. Put the bolt through the holes.
5. Tighten the auxiliary handle with the
knob.
FIG. 3
FIG. 4
