ASSEMBLY
Read and under
stand entire Operator’s M
anual for each
optional attachment used on this power
head and follow all warnings and instructions.
Failure to follow all instructions may result in
electric shock, fire and/or serious personal
injury.
To install the attachment to the power
head
This 80-Volt power head is compatible with
universal gas attachments.
The attachment connects to the power head
by means of a coupler device.
1. Loosen the attachment knob on the coupler.
2. Push in the release button located on the
attachment shaft. Align the button with the
guide recess on the power head coupler
and slide the two shafts together. Rotate the
attachment shaft until the button locks into
the positioning hole.
3. Tighten the attachment knob securely.
ASSEMBLY
UNPACKING
This product requires assembly.
• Carefully remove the product and any
accessories from the box.
• Inspect the product carefully to make sure
no breakage or damage occurred during
shipping.
• Do not discard the packing material
until you have carefully inspected and
satisfactorily operated the product.
• If any parts are damaged or missing, please
call
1-844-MSTR4CE (844-678-7423)
for
assistance.
GUARD
WARNING
To prevent accidental
starting that could cause serious personal
injury, always remove the battery pack from
the tool when assembling parts.
1. Remove the battery.
2. Invert the string trimmer to access the string
trimmer head.
3. Using a Phillips head screwdriver, remove
the pre-installed screws from the guard
plate on the string trimmer head.
4. Place the guard onto the string trimmer
head and slide the guard onto the head by
following the track on the head.
5. Align the screw holes on the guard with the
screw holes on the string trimmer head.
6. Insert the screws into the string trimmer
head, fastening the guard in place.
WARNING
