Mastervolt IVO Compact

SPECIFICATIONS IVO COMPACT
Model IVO Compact 12/25-3 (230V) 24/10-2 (230V) 12/20-3 (120V)
Article no. 43012500 43021000 43212500
DC
Charge voltage absorption (25°C) 14.25VDC 28.50VDC 14.25VDC
Charge voltage float (Wet; 25°C) 13.25VDC 26.50VDC 13.25VDC
Charge voltage float (Gel; 25°C) 13.80VDC 27.60VDC 13.80VDC
Total charge current 25A 10A 20A
DC consumption with connected battery <10mA <5mA <10mA
Number of main outlets 2 1 2
Number of slave outlets (3A) 1 1 1
Charge characteristics IUoUo / 3 stage / automatic / DIN 41772
Max. absorption time, reduced output 6 hours (adjustable) 6 hours (adjustable) 6 hours (adjustable)
Temperature compensation 30mV/°C 60mV/°C 30mV/°C
Voltage compensation Auto sense Auto sense Auto sense
Recommended DC fuse (Main) 30A-T 20A-T 25A-T
Recommended DC fuse (Slave) 5A-T 5A-T 5A-T
Wire size < 1.5m 6 mm²/AWG9 4mm²/AWG11 6 mm²/AWG9
Wire size > 1.5m 10mm²/AWG7 6mm²/AWG9 10mm²/AWG7
Recommended battery capacity 50~450Ah 50~300Ah 50~450Ah
AC
Nominal Input voltage 180~250VAC 180~250VAC 90~140VAC
Allowed input voltage range 90~250VAC 90~250VAC 90~250VAC
Frequency 50/60Hz 50/60Hz 50/60Hz
Full load consumption (230VAC) 419VA (@230VAC) 336VA (@230VAC) 334VA (@120VAC)
AC cable 3x0.75 mm² 3x0.75 mm² 3x0.75 mm²
Power factor / cos phi 0.99 0.99 0.99
General
Specified operation temperature 0…+60 °C, derating above +40°C, 5% per °C
Allowed operating temperature -20…+60 °C (may not meet all specified tolerances)
None operating temperature -25°…+85 °C (storage temperature)
Operating humidity 95% max., non-condensing
Efficiency 90% (at nominal input voltage)
Cooling Variofan ‘low noise’
Protections
Short circuiting Yes
Over heating Limited power by temperature sense circuit
Protection degree IP21
Options
Communication Quasi RS232, modular RJ12 connection, to alter set points and to change
characteristics (optional interface required) or to connect a temperature
sensor and/or remote panel.
Suitable as power supply without battery Yes, in the Forced to float mode.
Mechanical
Connections input/output Screw terminals, maximum wire size 16mm² / AWG 5
Dimensions (HxWxD) 228 x 153 x 82 mm; 8.9 x 6.1 x 3.2 inch
Mounting holes Diameter 5mm
Weight 2.4 kg / 3.9 lbs
Cabinet Anodized aluminium, strapton ABS blend, blue RAL 5021
Directives: - Generic emission and disturbances standard: EN 55014-1:1993
- Generic harmonic current emissions: EN61000-3-3:1995
- Generic & safety accreditations immunity standard: EN55014-2: 1997
- Electrostatic discharge : EN61000-4-2:1995
- Electrical fast transients: EN61000-4-4:1995
- Surge transient: EN61000-4-5:1995
- Conducted radio frequency disturbances: EN61000-4-6:1996
- Voltage dips: EN61000-4-11:1994
Set points software Default setting Set points software Default setting
Max. bulk/abs time 360min. Gel voltage setting 550mV
Return amps 2/16 of I-max Diode compensation setting 600mV
Abs voltage 14.25/28.50VDC DC alarm voltage 12.50/25.00VDC
Float voltage 13.25/26.50VDC DC alarm delay 30s
Forced to float 13.25/26.50VDC
