30
SPECIFICATIONS
Model Soladin 600 EU
Part number: 130000600
Manufacturer: Mastervolt, Amsterdam, the Netherlands
Operating temperature: -20°C to 40°C
Storage temperature: -20°C to 70°C
Relative humidity: max. 95%, non condensing
Protection degree: IP23
Safety class: Class II
Dimensions (H x W x D): 365 x 143 x 75 mm.
Weight: Approx. 2 kg.
Casing: Flame retardant plastic
Input (DC)
Nominal power @25 °C: 550W
PV power range: 160-700 Wp
MPP voltage range: 45-120V DC
Maximum voltage: 155V DC
MPP current: 8A
MPP tracker: dynamic MPP tracker
Start-up power: 1W DC @ 45V DC
String connection: MultiContact connectors
Grid output (AC)
Voltage: 230V (207V-253V)
Nominal power: 525W
Nominal current: 2,25A
Fuse: 3,15A -T
Frequency: 50 Hz (49,8-50,2 Hz)
Cos phi: 0,99
Stand-by power: < 0,05W AC
Maximum efficiency: 93%
EU efficiency: 91%
AC connection: AC cable with plug, 1,80 meter
Safety devices
Island protection: Voltage and frequency window monitoring; Maximum reaction time: 100 ms.
Power limiting: Automatic derating by increasing the operating voltage, depending on the
internal inverter temperature.
Temperature protection: Power derating at higher internal temperature
Reversed DC polarity: DC connection fully protected
Monitoring
Indicator: LED: green / red
Correct operation: Green, flashing. The longer the LED is lit, the more power is converted
Grid or inverter fault: Red, 6 different flashing codes
Compliance
CE compliance: Yes
EMC directive: EMC 89/336/EEG
Emission: EN 50081-1
Harmonics: EN 61000-3-2
Immunity: EN 50082-2
LV directive: LV 73/23/EEC
Electric safety: EN 60950
