MATALA Biosteps10 - Installation and Assembly; Scope of Supply; Installation Overview

Operation Guidelines for
BioSteps Pond Filter
Dear Customer
,
Congratulations on your selection of BioSteps10 as your pond filter! In the
following instructions and guidelines we provide you with important information for
installation, start-up and maintenance of your BioSteps10.
Scope of supply:
Please check your package for the following items:
INSTALLATION
!! Three BioSteps are connected in
parallel.
!! Two BioSteps are connected in
parallel.
!! Single BioSteps.
*The items in the above parts list are subject to replacement in function of improved filter characteristics.
Section 1
Contents:
Filter container
Filter cover
Inlet:universal hose adapter
1", 1 1/4", 1 1/2"
Sludge drain:Univeral hose tail + stopper
1 1/4", 1 1/2", + stopper 1"
QTY
1
1
1
1
Article no.
40001102
40002102
30819244
30819453
46191281
46191381
46191461
46191461
40003106
40004103
Matala filter mat Green
Matala filter mat Blue
Matala filter mat Grey
Matala filter mat Grey
Partioning screen
Outlet :Bulkhead fitting,
Compression/Push-Fit type,
2-steps:
50mm European fit is first inner diameter
followed by1 1/2” Sch40 PVC in deeper. This
section is a compression fit and requires firm
pressure to insert fully.
Section 2
Section 3
Section 4
Section 5
Section 6
2
2
2
2
1
1
1
