Plug and play recommendations:
complete lter systems for different pond sizes
Pond volume
Up to:
Liters
3000
6000
10000
15000
22500
30000
Gallons
800
1600
2660
4000
6000
8000
KOI CARP
Pond volume
Liters
1500
3000
5000
8000
12000
16000
Gallons
400
800
1330
2100
3200
4230
Liters/H
750-1200
1500 - 2500
2500 - 4000
4000 - 6000
6000 - 10000
10000 - 13500
Gallons/H
200-320
400 - 660
660 -1060
1060 – 1590
1590 – 2640
2640 - 3570
Recommend
hose diameter
for pump to filter
mm
25
32
40
40
40
40
inch
1”
1
¼”
1½”
1½”
1½”
1½”
UVC capacity
range
Wa tt
9 to 13
9 to 18
18
2 x 18
3 x 18
4 x 18
Recommend
Number of
EzBio 1 1
Recommend
Number of
EzBio 20
Recommend
Number of
Waterfall
1
1
2
2
1
1
Number of
BioSteps
1
1
1
2
3
4
1
1
1
2
3
4
OPTIONAL
Wa
te
rf
al
l
Pump capacity
(MAXIMUM RECOMMENDED FLOW RATE)
The choice of pump and UVC capacity should be made depending on the following variables:
- Height of Biosteps above water level → Pump should be able to give desired ow rate at lter position.
- Water garden pond with few sh → Try to achieve 500 to 900 gph pump ow rate.
- Koi sh pond → Try to achieve 900 to Max.1080 gph pump ow rate.
- Pond in direct sunlight or long hours of sun → Larger UVC
- Higher capacity sh stocking: more sh → Larger UVC
Our Biosteps design is GRAVITY FLOW back to the pond.
-
The outlet tting needs to be higher than the point of return at the waterfall or pond otherwise lter may overow.
- Also the distance from outlet tting to the pond should be kept as close as possible. Maximum distance for outlet pipe
should be less than 10 feet otherwise lter may overow.
Assembling and Start-up of the lter:
Attaching Inlet and Outlet Fittings to BioSteps
Outlet Fitting Installation:
▪Insert outow socket through upper hole.
▪Place O-ring on inside of lter and over the threads.
▪Hand tighten nut. Do not over tighten.
*note-A Sch 40 1.5” outlet pipe may be inserted
deeply into outlet bulkhead to extend water outow.
Three options for outlet connection to pond:
Option 1)
▪Use 1.5” schedule 40 PVC or ABS pipe from your local hardware store.
▪Slide the pipe into the outlet tting until it comes to a stop.
▪At this point push really hard and twist. Alternatively, tap the pipe with a
rubber mallet until secure. THE OUTLET FITTING HAS A
COMPRESSION FIT and no glue is required. The t is so tight you will
probably not be able to remove the pipe once inserted.
▪Tip: Lightly sand the very edge of the pipe to help get it started.
Option 2)
▪Install 2 inch rubber
coupler (from hardware
store) over the outlet
tting.
▪Insert 2 inch PVC pipe
into rubber coupler and
tighten screws.
