7
TEMPERATURE
Range Accuracy Overload Protection
32°F to 104°F
(0°C to 40°C)
±5°F/±3°C
-58°F to 392°F
(-50°C to 200°C)
392°F to 752°F
(200°C to 400°C)
±1.5%/±5°F
(±1.5%/±3°C)
±2%/±5°F
±2%/±3°C)
0.5A/250V fast fuse
WARNING
To avoid fire and/or electrical shock hazards, DO NOT connect the
thermocouples to circuits greater than 30 Vrms, 42.4 Vpk or 60
Vdc.
FREQUENCY
Range Resolution Accuracy Overload Protection
9.999Hz-
2MHz
0.001Hz ±(0.1% of
reading +5
digits)
250V DC or AC RMS
Sensitivity: <100kHz: 2V RMS; >100kHZ: 5V RMS
DUTY CYCLE/PULSE WIDTH/DWELL
Function Range Accuracy Overload Protection
Duty Cycle 0.1 to
99.9%
±(2.0% of
reading +5
digits)
Pulse Width 1 to 999
ms positive
±(3.0% of
reading ±2
ms)
Dwell Angle 1-12
cylinders
±(2.0% of
reading +5
digits)
0.5A/250V fast fuse
RPM
Range Resolution Accuracy Overload Protection
1-10000
RPM
1RPM ±(2.0% of
reading +5
digits)
0.5A/250V fast fuse
Frequency response: 50 - 400 Hz
