• 11 •
Troubleshooting
PROBLEM POSSIBLE CAUSE SOLUTION
Charger will
not turn on
when properly
connected.
AC outlet is dead.
Poor electrical connection.
Battery is defective.
Check for open fuse or circuit
breaker supplying AC outlet.
Check power cord and extension
cord for loose tting plug.
Have the battery checked.
Engine start does
not work.
Drawing more than the Engine Start
rate.
Failure to wait 3 minutes
(180 seconds) between cranks.
The charger may be overheated.
Battery may be severely discharged.
Crank time varies with the amount
of current drawn. If cranking draws
more than the Engine Start rate,
crank time may be less than 5
seconds.
When the Engine Start LED
blinks, wait 3 minutes of rest time
before the next crank.
The thermal protector may have
tripped and needs a little longer to
reset. Make sure the charger vents
are not blocked. Wait and try again.
On a severely discharged battery, use
the 50A Boost rate for 10 to 15
minutes, to help assist in cranking.
14. SPECIFICATIONS
Input .................................................. 120V AC @ 60Hz, 10A continuous, 65A intermittent
Output .......................................................................................6/12V DC, 15A intermittent
6/12V DC, 50A int., 60 sec. on, 120 sec. off
6/12V DC, 250A int., 5 sec. on, 180 sec. off
