Matco Tools MD79 - Electrical Specifications: Final Details; Regular Clamp-on DC+ACA Specifications; Hz Line Level Frequency Specifications; Non-Contact EF-Detection Specifications

21
Regular Clamp-on DC+ACA
RANGE
Accuracy
1) 2)
DC, 50Hz ~ 100Hz
60.00A
3)
, 600.0A
2.2% + 7d
100Hz ~ 400Hz
60.00A
3)
, 600.0A
2.7% + 7d
1) Induced error from adjacent current-carrying conductor: < 0.01A/A
2) Specified with DC-Zero mode applied to offset the non-zero residual
readings, if any
3) Add 10d to the specified accuracy @ < 9A
Hz Line Level Frequency
Function
Sensitivity
1)
(Sine
RMS)
Range
600V
50V
5.00Hz ~ 999.9Hz
60A (AmpTip
TM
)
40A
50.00Hz ~ 400.0Hz
60A, 600A
40A
50.00Hz ~ 400.0Hz
Accuracy: 1%+5d
1)
DC-bias, if any, not more than 50% of Sine RMS
Non-Contact EF-Detection
Typical Voltage
Bar-Graph Indication
20V (tolerance: 10V ~ 36V)
-
55V (tolerance: 23V ~ 83V)
- -
110V (tolerance: 59V ~ 165V)
- - -
220V (tolerance: 124V ~ 330V)
- - - -
440V (tolerance: 250V ~ 600V)
- - - - -
Indication: Bar-graph segments & audible beep tones proportional to
the field strength
Detection Frequency: 50/60Hz
Detection Antenna: Inside the top side of the stationary jaw
Probe-Contact EF-Detection: For more precise indication of live wires,
such as distinguishing between live and ground connections, use one
single probe to test via terminal COM for direct contact EF-Detection
with best sensitivity.
