MT1874 6" Heavy Duty DA Sander
ITEM PART NO. DESCRIPTION QTY.
1 RS187401 Hex Screw 1
2 RS187402 Washer 1
4 RS187404 Balance Nut 1
5 RS187405 Spacer 1
6 RS187406 Spring Washer 1
7 RS187407 Hex Screw Nut 1
8 RS187408 Pad 1
9 RS187409 Retaining Ring 1
10 RS187410 Wave Washer 1
11 RS187411 Pad Mounting Shaft 1
12 RS187412 Ball Bearing 1
13 RS187413 Stud 1
14 RS187414 Balancer 1
15 RS187415 Hex Screw 1
16 RS187416 Spring Washer 1
17 RS187417 Rotor Shaft 1
18 RS187418 Key 2
19 RS187419 Wave Washer 1
20 RS29120 Ball Bearing (6200ZZ) 2
21 RS187421 End Plate 2
22 RS187422 Rotor 1
23 RS187423 Rotor Vane 5
24 RS187424 Cylinder 1
25 RS187425 Pin 1
26 RS187426 O-Ring 1
ITEM PART NO. DESCRIPTION QTY.
27 RS187427 Retaining Ring 1
28 RS187428 Socket Head Cap Screw 4
30 RS187430 Motor Cover Plate 1
31 RS187431 Motor Gasket 1
32 RS187432 Housing 1
32-1 RS187432-1 Muffler 2
33 RS187433 Housing Cover 1
34 RS187434 Air Regulator 1
35 RS187435 O-Ring 3
36 RS187436 Retaining Ring 1
37 RS187437 Spring 1
38 RS187438 O-Ring 1
39 RS187439 Valve Stem 1
40 RS187440 O-Ring 1
41 RS187441 O-Ring 1
42 RS187442 Valve Bushing 1
43 RS187443 Carrier 1
44 RS187444 Screw 1
45 RS187445 Screw Nut 1
46 RS187446 Screw Washer 1
47 RS187447 Set Screw Nut 1
48 RS187448 Lever 1
49 RS187449 Pistol Grip 1
50 RS187450 Inlet Bushing 1
