Matco Tools SILVER EAGLE SE916 - Parts Breakdown; Component Identification

SE916 4 01/07/09
SE916 Air Hammer (Long Length Barrel)
Ref. No. Part No. Description Qty.
 1 RS90501 Housing(incl.#1-6,22) 1
 2 RS848002 Pin 2
 3 RS848003 InletBushing 1
 4 RS848004 Cap 1
 5 RS848005 O-Ring 2
 6 RS848006 Regulator 1
 7 RS848007 O-Ring 1
 8 RS848008V ValveStem 1
 9 RS848009 O-Ring 1
 10 RS848010 O-Ring 1
 11 RS848011 ValveBushing 1
 Ref. # Part # Description Qty.
12 RS848012 O-Ring 1
 13 RS848013 Spring 1
 14 RS848014 TriggerButton 1
 15 RS181112 MetalValveBlockAssembly 1
 20 RS848019 Piston 1
 21 RS848320 Cylinder 1
 22 RS90522 ComfortGrip 1
 23 SECR1 QuickChangeChiselRetainer 1
 24 RS848023 ExhaustDeflector 1
 26 RS87301 RetainerSpring(optional)
NotShown:RSMAHKCASEMoldedCase
