Operator's Manual
multipli 35
Mathias Bäuerle GmbH 3
CONTENTS
1. General 5
2. Specifications 6
3. Proper Handling of the Machine 7
4. Safety Instructions 9
5. Safety Features 13
6. Components of the Machine 14
7. Space Requirements 15
8. Operator Positions 15
9. Friction Feeder F 35 17
Function 17
Description 17
Setting the Format 18
Setting the Sheet Separation 19
Fanning the Paper Stack 20
Loading the Feed Table 20
10. Air Feeder S 32 21
Principle of Operation 21
Description 21
Setting the Format 22
Setting Sheet Separation 23
Setting the Air 23
Front Paper Stop 27
Setting the Sheet Gap 28
Positioning the Paper Stack 28
11. Air Feeder PBA 35 29
Principle of Operation 29
Description 29
Setting the Format 30
Setting the Sheet Separation 31
Setting the Sheet Gap 35
Positioning the Paper Stack 35
Balls in the Register Table 36
12. Buckle Fold Unit 35/2 and 35/4 37
Description 37
Fold Plate Positions 38
Inserting the Fold Plates and Deflectors 39
Setting the Fold Plate Stops 40
Long Fold Plate LFT 35 40
Setting Guide for Common Types of Fold 40
Adjusting the Ejector Rollers 43
Transfer Bridge 43
Roller Table 44
